Low Profile 45-Ton, 3-Axle Trailer
STANDARD FEATURES
- Construction: 130 KSI/100 KSI yield steel
- Axles: 3 Axles at 20,000 lbs. each; 54” axle spacing
- Suspension: Air-Ride Suspension w/ dump valve, scaling gauge, & rear axle lift
- Capacity: 45 Tons
- Wheels: 8-hole, hub piloted aluminum; outside wheels polished
- Tires: 235/75R x 17.5 – Hankook or Continental
- Decking: 3” Apitong outside, 2” Douglas Fir inside
- Paint: DuPont IMRON ELITE
- Goosenecks: Mechanical Removable wide neck with a single kingpin
- Deck Height: 27” nominal center of deck (dependent on 5th wheel height)
- Over-front loading: 10”
- Over-rear loading: 36”
- Overall Length: 45’-8” with standard 21’-6” deck, gooseneck, 54” axle spacing, and standard tail
OPTIONAL FEATURES
- Deck Lengths to 24’ 60 Inch Axle Spacing
- 16” Longer Gooseneck Second kingpin
- Air operated “RoboLink” & Deck Latch release (US PAT #8752854, 9272591)
- Manual or Sliding Outriggers Disc brakes with ABS
- Full wheel covers Tire Inflation System
- Lockable tool boxes in wide neck Front & rear loading ramps
- ”D” Rings
- Cleral Scale System
- Chain boxes w/ optional lids Excavator deck well or pan
- Rear Diamond Ramp storage w/ air lock Spare tire with lockable mount
- Electric winch on gooseneck
- 20” Longer sloping tail for rear loading
GUARANTEED OVER-THE-BACK LOADING
